品牌

京东方

型号

BMXB0-B541

液晶屏/LCD Panel

屏幕尺寸/Screen Size (Diag.)

110”

点分辨率/Resolution

3840*2160

宽高比/Aspect Ratio

16:9

面板亮度/Brightness

500cd/m2 (Center 1point ,Typ.)

对比度/Contrast Ratio

1200:1

可视角度/Viewing Angle(CR>10)

178°

显示区域/Display area

2436.48(H) x 1370.52(V)

背光寿命/Backlight Life

50000Hrs

硬件配置/Hardware configuration

芯片组/Chipset

ZG459

声音/Sound

内置扬声器/Built-in Speakers

10W*2(8Ω)

输入输出接口/

I/O interface

高清数字/DP 1.2 in

2

高清数字/DP out

1

高清数字/HDMI 1.4

2

高清数字/HDMI 2.0

2

串口/RS232/RJ45

2

电源/Power

输入电源/Input Power

100-240V

功耗/Power Consumption (Typical)

550W

待机功耗/Power Consumption (Standby)

＜0.5W

环境条件/Environmental Conditions

工作温度/Operating Temp.

0-40℃

工作湿度/Operating Humid

20%-80%

产品规格/ Physical Spec

整机尺寸/Dimension (WxHxD)

2474*1408*91mm

包装尺寸/Package Dimension

2680 * 1730* 320mm

净重/Net Weight

80Kg

毛重/Gross Weight

110Kg

壁挂孔位/Wall hanging size(mm)

1500*800
